Controller
Function characteristics:
18/22Groups of light control output, the typical drive current5A。
16A running phase, can meet most of the intersection traffic rules.
16A working time, improve the efficiency of road traffic.
There are10A control scheme of multiple calls at any time.
State of emergency in yellow flashing from time to time, and all kinds of green channel (with handheld remote control).
, according to the simulated intersection signal panel have a simulated road, simulation run lanes and sidewalks, set the be clear at a glance.
RS232Communication interface and the upper machine, can be set up convenient laptop signal operation parameters.
Working parameters automatically fall protection, can save ten years.
Can be adjusted online, check and Settings.
Embedded central control system, work more stable and reliable.
Technical parameters:
Execution standard:GA47-2002DC12V/2
Input power supply: -220V±10% 50Hz
Ambient temperature:- 40 ℃ to 80 ℃
The clock precision:±2S/5day
Output power:1000W/Lk.
Signal power:2W
' ":250*190*110mm
According to traffic signal control machineGB25280-2010"Road traffic signal control machine" standards;
